Technische Übersicht
Rahmenset
Rahmen:
Alpenchallenge AC02 - aluminium | triple butted aluminium
Gabel:
triple butted aluminium
Cockpit
Lenker:
BMC LFB03
Vorbau:
BMC LSM03
Sattel
Sattelstütze:
BMC LSP03
Sattel:
Selle Royal Sirioaddle
Antrieb
Übersetzung:
27
Kurbel:
Shimano M391 | 48-36-26T
Kassette:
Shimano HG200-9 | 11-34
Kette:
KMC HG53
Umwerfer:
Shimano Alivio T4000
Schaltwerk:
Shimano Alivio M4000
Schalthebel:
Shimano Alivio M4000 | Rapidfire Plus
Bremsen
Bremshebel:
Shimano M355 | RT30 Rotors
Räder
Felgen:
Alex X2100
Naben (V/H):
Shimano RM33
Bereifung:
Continental Sport Contact II | 700 x 37c
| Size | S | M | L | XL |
|---|---|---|---|---|
| Rider Height | ||||
| Reach | 390 | 405 | 415 | 430 |
| Stack | 530 | 571 | 591 | 630 |
| Bar Drop | ||||
| Bar Reach | ||||
| Bar Rise | ||||
| Bar Sweep | ||||
| Bar Width | 600 | 600 | 600 | 600 |
| Base Bar Drop Flat Cockpit | ||||
| Base Bar Drop V-Cockpit | ||||
| Base Bar Reach Flat Cockpit | ||||
| Base Bar Reach V-Cockpit | ||||
| BB Drop | 50 | 50 | 50 | 50 |
| BB Drop (SLACK) | ||||
| BB Drop (STEEP) | ||||
| BB Height (SLACK) | ||||
| BB Height (STEEP) | ||||
| Chainstay | ||||
| Crank Length | 170 | 170 | 175 | 175 |
| LT | BB Drop (SLACK) | ||||
| LT | BB Drop (STEEP) | ||||
| LT | BB Height (SLACK) | ||||
| LT | BB Height (STEEP) | ||||
| LT | Chainstay | ||||
| LT | Fork Length | ||||
| LT | Fork Rake | ||||
| LT | Frame Size | ||||
| LT | Front Center (SLACK) | ||||
| LT | Front Center (STEEP) | ||||
| LT | Head Tube | ||||
| LT | HT Angle (SLACK) | ||||
| LT | HT Angle (STEEP) | ||||
| LT | Reach (SLACK) | ||||
| LT | Reach (STEEP) | ||||
| LT | Rider Height | ||||
| LT | Seat Tube | ||||
| LT | ST Angle @750mm Saddle Height (SLACK) | ||||
| LT | ST Angle @750mm Saddle Height (STEEP) | ||||
| LT | ST Angle Actual (SLACK) | ||||
| LT | ST Angle Actual (STEEP) | ||||
| LT | ST Angle Effective (SLACK) | ||||
| LT | ST Angle Effective (STEEP) | ||||
| LT | Stack (SLACK) | ||||
| LT | Stack (STEEP) | ||||
| LT | Stand Over Height (80 in Front of BB) | ||||
| LT | Stand Over Height (Lowest Point) | ||||
| LT | Top Tube (SLACK) | ||||
| LT | Top Tube (STEEP) | ||||
| LT | Wheelbase (SLACK) | ||||
| LT | Wheelbase (STEEP) | ||||
| ST | BB Drop (SLACK) | ||||
| ST | BB Drop (STEEP) | ||||
| ST | BB Height (STACK) | ||||
| ST | BB Height (STEEP) | ||||
| ST | Chainstay | ||||
| ST | Fork Length | ||||
| ST | Fork Rake | ||||
| ST | Frame Size | ||||
| ST | Front Center (SLACK) | ||||
| ST | Front Center (STEEP) | ||||
| ST | Head Tube | ||||
| ST | HT Angle (SLACK) | ||||
| ST | HT Angle (STEEP) | ||||
| ST | Reach (SLACK) | ||||
| ST | Reach (STEEP) | ||||
| ST | Rider Height | ||||
| ST | Seat Tube | ||||
| ST | ST Angle @750mm Saddle Height (SLACK) | ||||
| ST | ST Angle @750mm Saddle Height (STEEP) | ||||
| ST | ST Angle Actual (SLACK) | ||||
| ST | ST Angle Actual (STEEP) | ||||
| ST | ST Angle Effective (SLACK) | ||||
| ST | ST Angle Effective (STEEP) | ||||
| ST | Stack (SLACK) | ||||
| ST | Stack (STEEP) | ||||
| ST | Stand Over Height (80 in Front of BB) | ||||
| ST | Stand Over Height (Lowest Point) | ||||
| ST | Top Tube (SLACK) | ||||
| ST | Top Tube (STEEP) | ||||
| ST | Wheelbase (SLACK) | ||||
| ST | Wheelbase (STEEP) | ||||
| Fork Length | 405 | 405 | 405 | 405 |
| Fork Rake | 48 | 48 | 48 | 48 |
| Frame Size | ||||
| Front Center | 608 | 637 | 654 | 682 |
| Front Center (SLACK) | ||||
| Front Center (STEEP) | ||||
| Head Tube | 122 | 165 | 187 | 228 |
| Head Tube Angle | 71 | 71 | 71 | 71 |
| HT Angle (SLACK) | ||||
| HT Angle (STEEP) | ||||
| Pad Reach Flat Cockpit | ||||
| Pad Reach V-Cockpit | ||||
| Pad Stack Flat Cockpit | ||||
| Pad Stack V-Cockpit | ||||
| Reach (SLACK) | ||||
| Reach (STEEP) | ||||
| Rear Center | 436 | 436 | 436 | 436 |
| Saddle Height Range | ||||
| Seat Angle | 73 | 72.5 | 72.5 | 72 |
| Seat Tube | 440 | 510 | 560 | 610 |
| Seatpost Drop | ||||
| Seatpost Length | 350 | 350 | 350 | 350 |
| Seatpost Offset | 15 | 15 | 15 | 15 |
| ST Angle @750mm Saddle Height (SLACK) | ||||
| ST Angle @750mm Saddle Height (STEEP) | ||||
| ST Angle Actual (SLACK) | ||||
| ST Angle Actual (STEEP) | ||||
| ST Angle Effective (SLACK) | ||||
| ST Angle Effective (STEEP) | ||||
| Stack (SLACK) | ||||
| Stack (STEEP) | ||||
| Stand Over Height (80 in Front of BB) | ||||
| Stand Over Height (Lowest Point) | ||||
| Standover Height | ||||
| Stem Angle | +/- 12 | +/- 12 | +/- 12 | +/- 12 |
| Stem Length | 90 | 100 | 110 | 120 |
| Top Tube | 552 | 585 | 601 | 634 |
| Top Tube (SLACK) | ||||
| Top Tube (STEEP) | ||||
| Trail | 68 | 68 | 68 | 68 |
| Wheelbase | 1039 | 1068 | 1085 | 1113 |
| Wheelbase (SLACK) | ||||
| Wheelbase (STEEP) |
