BMC-23-10615-002

Timemachine ONE

NEON RED / BLACK

Transmisión Shimano 105
Ruedas Shimano WH-RS100
Profile WING 10a Basebar / Sonic Ergo 35A Aerobar

Precio habitual $3,299.00 Precio de oferta$2,639.00
/

SKU: 30002557
Talla

Timemachine ONE

Piezas y accesorios

La Timemachine ONE se beneficia de nuestr Vmax Aero Design y del increíble ajuste posicional, en un paquete menos complejo. Su cuadro de carbono incluye punteras deslizantes, tija de sillín aerodinámica de doble posición y una caja de almacenamiento trasera, mientras que la horquilla tiene un diseño de bisagra. Cuenta con una potencia convencional con un manillar Profile Design y extensiones Sonic, el sillín Fizik Mistica y un grupo Shimano 105 con pinzas de freno direct mount y palancas de cambio Dura-Ace, todo ello sobre ruedas Shimano RS100 con una altura de la llanta de 24 mm.

Tecnología

Descripción técnica

Cuadro

Cuadro:
Timemachine Carbon with Vmax Aero Design and P2P Positioning SyStem | P2P Dual-Mount Aeropost Configuration | Internal Di2 Battery Mount | PF86 Bottom Bracket | Rear Storage Box | Sliding Dropouts

Horquilla:
Timemachine Carbon with Vmax Aero Design Hinge Design

Cockpit

Manillar:
Profile WING 10a Basebar / Sonic Ergo 35A Aerobar

Potencia:
BMC RSM01

Tija de Sillín:
Timemachine Carbon V-Max Aero Seatpost

Sillín:
Fizik Mistica Mg

Transmisión

Marchas:
2x11

Platos y Bielas:
SHIMANO 105 FC-R7000 53-39T

Cassette:
SHIMANO 105 CS-R7000 11-30T

Cadena:
SHIMANO CN-HG601-11

Desviador Delantero:
SHIMANO 105 FD-R7000

Cambio Trasero:
SHIMANO 105 RD-R7000

Manetas de Cambio:
SHIMANO Dura Ace SL-BSR1 Bar End

Frenos

Pinzas de Freno:
SHIMANO 105 BR-R7010 Direct Mount

Ruedas

Llantas:
SHIMANO WH-RS100 - 24mm

Bujes:
SHIMANO WH-RS100

Neumáticos:
Vittoria Zaffiro Pro - 25mm

Accesorios

Aerocore Bottle Cages

Información adicional

Anchura Máx. de Neumático:
27mm (Measured Width)

Clasificación ASTM:
Level 1

Límite de Peso:
110 Kg

SizeSS-MM-LL
Rider Height<170172-180178-188186-196
Reach393377418442
Stack480515515556
Bar Drop
Bar Reach160160160160
Bar Rise
Bar Sweep
Bar Width400420420420
Base Bar Drop Flat Cockpit
Base Bar Drop V-Cockpit
Base Bar Reach Flat Cockpit
Base Bar Reach V-Cockpit
BB Drop58686868
BB Drop (SLACK)
BB Drop (STEEP)
BB Height (SLACK)
BB Height (STEEP)
Chainstay
Crank Length165170170172.5
LT | BB Drop (SLACK)
LT | BB Drop (STEEP)
LT | BB Height (SLACK)
LT | BB Height (STEEP)
LT | Chainstay
LT | Fork Length
LT | Fork Rake
LT | Frame Size
LT | Front Center (SLACK)
LT | Front Center (STEEP)
LT | Head Tube
LT | HT Angle (SLACK)
LT | HT Angle (STEEP)
LT | Reach (SLACK)
LT | Reach (STEEP)
LT | Rider Height
LT | Seat Tube
LT | ST Angle @750mm Saddle Height (SLACK)
LT | ST Angle @750mm Saddle Height (STEEP)
LT | ST Angle Actual (SLACK)
LT | ST Angle Actual (STEEP)
LT | ST Angle Effective (SLACK)
LT | ST Angle Effective (STEEP)
LT | Stack (SLACK)
LT | Stack (STEEP)
LT | Stand Over Height (80 in Front of BB)
LT | Stand Over Height (Lowest Point)
LT | Top Tube (SLACK)
LT | Top Tube (STEEP)
LT | Wheelbase (SLACK)
LT | Wheelbase (STEEP)
ST | BB Drop (SLACK)
ST | BB Drop (STEEP)
ST | BB Height (STACK)
ST | BB Height (STEEP)
ST | Chainstay
ST | Fork Length
ST | Fork Rake
ST | Frame Size
ST | Front Center (SLACK)
ST | Front Center (STEEP)
ST | Head Tube
ST | HT Angle (SLACK)
ST | HT Angle (STEEP)
ST | Reach (SLACK)
ST | Reach (STEEP)
ST | Rider Height
ST | Seat Tube
ST | ST Angle @750mm Saddle Height (SLACK)
ST | ST Angle @750mm Saddle Height (STEEP)
ST | ST Angle Actual (SLACK)
ST | ST Angle Actual (STEEP)
ST | ST Angle Effective (SLACK)
ST | ST Angle Effective (STEEP)
ST | Stack (SLACK)
ST | Stack (STEEP)
ST | Stand Over Height (80 in Front of BB)
ST | Stand Over Height (Lowest Point)
ST | Top Tube (SLACK)
ST | Top Tube (STEEP)
ST | Wheelbase (SLACK)
ST | Wheelbase (STEEP)
Fork Length374374374374
Fork Rake45454545
Frame Size
Front Center580578619649
Front Center (SLACK)
Front Center (STEEP)
Head Tube97111111153
Head Tube Angle71.571.571.571.5
HT Angle (SLACK)
HT Angle (STEEP)
Pad Reach Flat Cockpit
Pad Reach V-Cockpit
Pad Stack Flat Cockpit
Pad Stack V-Cockpit
Reach (SLACK)
Reach (STEEP)
Rear Center393-404393-404393-404393-404
Saddle Height Range630 - 780660 - 850660 - 850700 - 880
Seat Angle71.5 - 80.871.5 - 80.871.5 - 80.871.5 - 80.8
Seat Tube495550550592
Seatpost Drop
Seatpost Length
Seatpost Offset27 / 9 / -9 / -2727 / 9 / -9 / -2727 / 9 / -9 / -2727 / 9 / -9 / -27
ST Angle @750mm Saddle Height (SLACK)
ST Angle @750mm Saddle Height (STEEP)
ST Angle Actual (SLACK)
ST Angle Actual (STEEP)
ST Angle Effective (SLACK)
ST Angle Effective (STEEP)
Stack (SLACK)
Stack (STEEP)
Stand Over Height (80 in Front of BB)
Stand Over Height (Lowest Point)
Standover Height755797797838
Stem Angle±8±8±8±8
Stem Length9090100110
Top Tube
Top Tube (SLACK)
Top Tube (STEEP)
Trail60606060
Wheelbase96496710081038
Wheelbase (SLACK)
Wheelbase (STEEP)
