Descripción técnica
Cuadro
Cuadro:
257 Premium Aluminium | Smoothwelded | Staggered Top Tube | Powder Coat Finish | Internal Cable Routing | Flat Mount Disc | 12 x 142mm Thru-Axle
Horquilla:
257 Premium Aluminium | Fender Mounts | Flat Mount Disc | 12 x 100mm Thru-Axle
Cockpit
Potencia:
BMC RSM 01
Manillar:
BMC LSB 03
Seat
Tija de Sillín:
BMC LSP 02t
Sillín:
Selle Royal Vivo Women's
Transmisión
Platos y Bielas:
Gates S150 CDN
Platos:
55T
Potenciómetro:
Cassette:
Gates CDN
Tamaño del cassette:
24T
Cadena:
Gates Belt 120 CDX
Desviador Delantero:
Cambio Trasero:
Manetas de Cambio:
SHIMANO Nexus | Rapidfire Plus
Marchas:
1 x 8
Pedalier:
BSA Threaded Bottom Bracket
Frenos
Pinzas de Freno:
SHIMANO MT200 Levers | BR-U300 Calipers
Discos:
SHIMANO RT10 Rotors
Tamaño del disco:
180 / 180mm
Ruedas
Llantas:
PFR300
Bujes:
CL-712 | SHIMANO Nexus 8
Neumáticos:
Pirelli Cycl-e GT | 37mm
Información adicional
Paso de rueda:
42mm
Clasificación ASTM:
Level 2
Límite de peso del sistema:
120kg
| Size | S | M |
|---|---|---|
| Rider Height | <170 | 170-185 |
| Reach | 390 | 420 |
| Stack | 590 | 640 |
| Bar Width | 600 | 600 |
| BB Drop | 67 | 67 |
| Crank Length | 170 | 170 |
| Fork Length | 408 | 408 |
| Fork Rake | 45 | 45 |
| Front Center | 632 | 680 |
| Head Tube | 165 | 219 |
| Head Tube Angle | 70 | 70 |
| Rear Center | 440 | 440 |
| Seat Angle | 74 | 74 |
| Seat Tube | 450 | 500 |
| Seatpost Length | 350 | 350 |
| Seatpost Offset | 15 | 15 |
| Standover Height | 644 | 653 |
| Stem Angle | ±8 | ±8 |
| Top Tube | 559 | 603 |
| Trail | 75 | 75 |
| Wheelbase | 1063 | 1111 |
